Feature:

1.Camera Sensor：High Resolution CMOS/CCD to choose

2.With white LED light to fill light

3.Camera is made of ABS plastic material,which matched with metal casing, color can be matched according to customer requirements;

Specification:

Model:                          F1

Type:                             Single Family

Camera:                         Color CMOS / CCD

Resolution:                  More than  420 TV lines / 600 TV lines

Illumination:                 0LUX

With Six white LED light  fill light

Ring tones:                   25

Rainproof:                    Yes

Input voltage:              Supply from the indoor unit power (DC12V)

Standby current:         0mA

Operating current:      100mA

Working temperature:     -35 ℃ ~ +75 ℃

Operating humidity:      ≤ 90%

Equipment size:             70 * 157 * 25MM

Installation method:       hanging
